Laboratory description

The Laboratory for Geodetic Measurement Techniques has a comprehensive range of classical surveying instruments for a wide variety of surveying purposes, including the necessary accessories. In addition, there is a wide range of state-of-the-art surveying equipment for teaching and research activities, including professional surveying drone systems (UAV, unmanned aerial vehicle).

In the laboratory a large number of supervised practical exercises for students of surveying, civil engineering and industrial engineering and construction and real estate take place every semester. The laboratory equipment is also used every semester for numerous bachelor and master theses as well as for research projects.

A number of surveying test devices are permanently installed in the basement. Special electronic instruments, such as inclination sensors and a high-precision laser interferometer, are available here if required. The measuring cellar also offers a generous open space for variable experiments and stationary investigations under laboratory conditions.

Totalstations, Multistations, Theodolites

The laboratory has around 20 current total stations from Leica, Topcon and Trimble. Some of the devices have built-in cameras or are equipped with the scanning functionality (multistations).

In addition, the corresponding accessories (reflectors, target plates, tripods, robotic equipment, etc.) are of course available in large numbers.

With this extensive instrumentation, in addition to the standard measurement procedures, integrated measurement procedures (with GNSS, graphic field book, video camera), "one-man measurement procedures", reflectorless measurements and measurements of highest accuracy can be carried out.

.

GNSS Systems

In the laboratory, around 15 GNSS receivers from Leica, Topcon and Trimble are available and can be used with the existing equipment for both static and kinematic measurements. Besides a post-processing evaluation, the devices can also be used with the different real-time services (AXIO-NET, HxGN SmartNet (Leica), Trimble-VRSNow.

Together with total stations, the GNSS receivers are also used for integrated measurement procedures.

Levels

In the laboratory there are 8 "digital" compensator levels from the companies Leica and Trimble, and about 20 "analog" compensator levels from Askania, Breithaupt, Fennel, Kern, Leica, Nikon, Wild and Zeiss. Levels also include an extensive range of levelling staffs, including around 10 pairs of precision barcode levelling staffs.

The available instruments allow both accuracy classes to be covered for levelling (engineering levelling, precision levelling).

Laser scanner and 3D measuring systems

For more extensive 3D capturing, 5 "classic" laser scanners with corresponding accessories such as target spheres and scanner targets are available.

  • Faro Focus3D
  • Faro Focus 3D X330
  • Leica HDS7000
  • Leica ScanStation P20
  • Leica BLK360

In addition, further 3D measuring systems for industrial applications (Faro Freestyle, GOM Atos, GOM Tritop) or mobile mapping systems (GEOSLAM ZEB1, Leica BLK3D) can be used.

Survey drones / UAV (Unmanned Aerial Vehicle)

A total of 6 surveying drones can be used in teaching, for final theses or for research projects. They are supervised by the 5-member pilot team of the Surveying Department, which is the holder of the drone knowledge certificate.

The following survey drones are available:

  • DJI Inspire 1
  • Topcon Falcon 8
  • DJI Phantom4 pro (3x)
  • DJI Matrice 210 RTK V2

All use an RGB camera as a sensor, with the DJI Inspire 1 additionally equipped with a Parrot Sequoia near infrared camera. The DJI Matrice 210 RTK V2 can be equipped with additional sensors in the future thanks to its design and a special interface.

Graphical field books, fieldcomputers

The equipment of the graphic field books / field computers includes five tablet PCs and more than 10 field computers with Windows or Windows CE operating system (Leica, Mettenmeier, Panasonic, Topcon, Trimble). All graphic fieldbooks and field computers can communicate via WLAN or Bluetooth interfaces with different measuring devices and external sensors, so that many flexible applications in research and teaching are possible.

A wide range of installed onboard programs or apps can be used to control the various measuring devices.

Other measuring instruments

In the laboratory there are other devices available which are not listed in the other categories:

  • Scanner camera / TOF camera (Mesa Imaging SwissRanger SR4000)
  • Multi-Camera Rover (Trimble V10)
  • Laser interferometer (Hewlett Packard HP-5508)
  • Laser distance meters (Leica Disto)
  • Precision Nadir Plumb
  • Construction laser / rotary laser
  • Weather Station (DAVIS)

Other equipment

The other equipment includes many "little things", but some of them are indispensable for surveying exercises, bachelor or master theses. These include, for example: Measuring tapes, pole straighteners, plumbs, ranging-rods, pole stands, thermometers, barometers, compasses, clinometers, field book frames, radios, safety material (pylons, warning vests, warning signs, helmets), marking material, field umbrellas.
